SCHURTER MSS IO Switches
Schurter MSS IO Switches are metal line switches designed with a robust combination of thermoplastic and metal materials to ensure long-term durability. These switches comply with RoHS directives, confirming their environmentally responsible material composition. The MSS IO Switches feature an operating temperature range from -40°C to +85°C and a supply voltage of 24VDC. These components come with an actuating force range from 1N to 3N and a mounting depth of 28.9mm. Typical applications include industrial automation, food processing, and medical equipment.
Features
- Come with the IO-link communication protocol
- Hygienic operation
- Insensitive to water
- Light pressure triggering
- Multicolor illumination
- No moving parts
- Side illumination
Applications
- Food processing
- Industrial automation
- Medical equipment
Technical Specifications
| Parameters | Values |
|---|---|
| Actuating Force Range | 1N to 3N |
| Mounting Depth | 28.9mm |
| Operating Temperature Range | -40°C to +85°C |
| Rated Voltage | 24VDC |
| Shock Protection | IK06 |
