ITT Cannon D-Sub Connectors

ITT Cannon D-Subminiature (D-Sub) Connectors offer a ruggedized interconnect solution that transfers data, power, and signal in a small, weight-saving design. The D-Sub connectors come with a wide array of space grade, standard D-Sub, combo-D, sealed, double density, and accessories. The D-Sub MIL-Spec connectors are standard density connectors with fixed contacts in solder cups, straight, and 90° PC terminations. These D-Sub connectors offer a 7.5A standard current rating and operating voltage of up to 1000V AC. Typical applications include defense, rail, aerospace, medical, and industrial.

Features

• Accessory back shell and screw-lock hardware
• Crimp, solder cup, PCB, and wire wrap terminations
• High-bandwidth ethernet contacts
• Selected parts qualified to NASA and SAE standards
• Standard, high-density, double-density, MIL-DLT-24308, and combo-D layouts
• Suitable for a variety of cable and printed circuit board options

• Up to 104 contact positions:
  • Double density pin count: 19, 31, 52, 79, 100
  • High-density pin count: 15, 26, 44, 62, 78, 104
  • Standard pin counts: 9, 15, 25, 37, 50
• Wide range of shell materials and plating options

Applications

• Aerospace
• Commercial avionics
• Defense
• Heavy equipment
• In-flight entertainment
• Industrial
• Medical
• Rail
• Robotics

Technical Specifications

Video

This ITT Cannon D-Subminiature Connectors video describes the technical specifications and the features of the product. These connectors are standard density connectors with fixed contacts in solder cups, straight, and 90° PC terminations.

Additional Resources

• ITT Cannon D-Sub Aluminum Backshells Product Specifications (Download from ITT Cannon)
• ITT Cannon D-Sub Accessories Product Catalog (Download from ITT Cannon)
